Stainless Steel Cylinder 1-1/16 In. Bore 4 In. Stroke
Stainless Steel Cylinder 1-1/16 In. Bore 4 In. Stroke
Description
The piston rod is extended by pneumatic pressure and automatically returns to its initial position with the help of an internal return spring, providing smooth and safe retraction.
The output force varies depending on the effective piston area and the applied pressure. The forces differ in extension and retraction, since the rod reduces the active surface area during retraction. This design ensures precise control, consistent force, and reliable performance over time.
Technical Specifications
- Product Series83
- Product TypePneumatic Cylinders
- Nominal Diameter (in)1-1/16
- Bore Size (in)1-1/16
- Stroke Length (in)4
- Stroke Length (mm)101.6
- Return MechanismSpring
- Cylinder Action TypeSingle
- Compatible With Cylinder Bore Diameters (in)1-1/16
- With ExhaustYes
- Magnetized Piston IncludedNo
- Outlet Quantity1
Documents
There are no documents available.
Warranty
G1: 1 Year Warranty
The replacement warranty (G) means that the product, or parts of the product, may be replaced by a new product and/or parts or equivalent. The warranty covers any manufacturing or material defect. The warranty does not cover installation and/or removal costs incurred by the customer nor shipping costs.
Failure to comply with the technical specifications, failure to follow the guidelines in the installation guide and/or the technical sheet, inappropriate or excessive tightening, misuse and/or abuse, failure to comply with the maintenance guidelines, normal wear, contamination and/or corrosion, neglect/accident, unauthorized repair attempt and/or disassembly, alteration of the product, assembly with incompatible products.
If the product contains one or several parts with a 1-month limited warranty (GL), these parts will be excluded from the 1-year warranty (G1).
