Zinc Lockable Exhaust Shut-Off Valve 1/2 (F) NPT S50 - Discontinued
Zinc Lockable Exhaust Shut-Off Valve 1/2 (F) NPT S50 - Discontinued
Description
Shut-off valve locks in closed position with standard padlock so it cannot be opened inadvertently (2 x 8mm holes).
3-port, 2-position shut-off valve vents pressure downstream when closed.
Meets OSHA 29 CFR Part 1910.147
Possibility of installation directly on AIRFLO FRLs using standard spacers (included).
Technical Specifications
- Product Series50
- Product TypeShut-Off Valves
- LockableYes
- Minimum Fluid Temperature (°C)4
- Maximum Fluid Temperature (°C)66
- Maximum Inlet Pressure (PSI)300
- Inlet Connection TypeThreaded
- Inlet Connection SubtypeNPT
- Inlet Nominal Size (Imperial)1/2 in
- Inlet Connection GenderFemale
- Compatible FluidsAir
Documents
There are no documents available.
Warranty
R2: 2 Year Repair
The repair warranty (R) means that the product or parts of the product will be repaired or refurbished. The warranty covers any manufacturing or material defect. The warranty does not cover installation and/or removal costs incurred by the customer nor shipping costs.
Failure to comply with the technical specifications, failure to follow the guidelines in the installation guide and/or the technical sheet, inappropriate or excessive tightening, misuse and/or abuse, failure to comply with the maintenance guidelines, normal wear, contamination and/or corrosion, neglect/accident, unauthorized repair attempt and/or disassembly, alteration of the product, assembly with incompatible products.
If the product contains one or several parts with a 1-month limited warranty (GL), these parts will be excluded from the 2-year warranty (R2).
See all the solutions offered by TOPRING to repair or replace the components of filters, regulators, and lubricators (drains, elements, bowls, pressure gauges, etc).
