100 mm Aluminum Compact Connection Expansion Joint S08
100 mm Aluminum Compact Connection Expansion Joint S08
Description
This expansion fitting is designed to absorb the effects of thermal variation in tubing, maintaining network stability and performance even under fluctuating temperature conditions. It prevents mechanical stress and deformation caused by thermal expansion, extending the system’s service life.
This compact connection fitting is also ideal for tube assembly in compressor rooms where space is limited. Its clever design allows multiple fittings to be directly connected together, creating clean, organized, and space-efficient configurations. This setup ensures a quick, safe, and professional installation.
Compatible with a standard ANSI flange, it easily connects to a compressor, dryer, or existing compressed air network. This fitting provides a durable, efficient, and scalable solution — perfectly suited for compact installations and demanding industrial environments where reliability and precision are key.
Technical Specifications
- Product Series08
- Product TypeExpansion Fittings
- ShapeStraight
- Sub-BrandSERIES 08
- ColorBlack, Silver
- Body MaterialAluminum
- Compatible FluidsAir, Neutral and Inert Gases
- With CRNNo
- Maximum Vacuum Level (Inhg)-29.84
- Minimum Fluid Temperature (°C)-20
- Maximum Fluid Temperature (°C)80
- Inlet Quantity2
More Information
Documents
Warranty
G10: 10 Year Warranty
The replacement warranty (G) means that the product, or parts of the product, may be replaced by a new product and/or parts or equivalent. The warranty covers any manufacturing or material defect. The warranty does not cover installation and/or removal costs incurred by the customer nor shipping costs.
Failure to comply with the technical specifications, failure to follow the guidelines in the installation guide and/or the technical sheet, inappropriate or excessive tightening, misuse and/or abuse, failure to comply with the maintenance guidelines, normal wear, contamination and/or corrosion, neglect/accident, unauthorized repair attempt and/or disassembly, alteration of the product, assembly with incompatible products.
If the product contains one or several parts with a 1-month limited warranty (GL), these parts will be excluded from the 10-year warranty (G10).
TOPRING compressed air piping systems are guaranteed against any manufacturing or material defect, under normal conditions of use and maintenance. TOPRING declines all responsibility and excludes from its warranty defects resulting from: poor design, incorrect assembly and/or bad installation, and inadequate maintenance. Installation and/or alteration of the system by a person not qualified as an installer voids the warranty. The buyer, user, and installer are required to fully read the design and installation guides for compressed air piping systems, available at TOPRING.com. The warranty is void if the design, installation, and maintenance of the piping system are not carried out in accordance with the directives, instructions, and specifications for design, installation and maintenance recommended by TOPRING.
Disclaimer
Please note that while we make every effort to accurately represent our products on our website, slight variations in design and appearance may occur due to factors such as manufacturing processes and materials used.
