Technical specifications and certifications

• Size: 28 mm
• Maximum Working Pressure: 200 PSI
• Working Temperature: -9 to 99 °C

Material(s):
• Body: Brass
• Ball: Chrome plated brass
• Seals: Reinforced PTFE
• Handle: Steel with PVC

PUSH-TO-CONNECT FITTINGS
• Body: Brass
• Release Sleeve: Fiber glass reinforced polyamide composite
• Release Collar: Polyamide
• Retaining Ring: Stainless steel
• Spacer: Acetal resin
• O-Ring: Nitrile rubber

Features and benefits

• Suitable for aluminum pipes (and nylon pipes Series 5)
• Outside diameters: 15, 22 and 28 mm
• Quick assembly
• Limited fitting expansion under pressure, resulting in dimensionally stable installations
• No threading, no soldering, no sealing materials required
• Full flow design
• Fully reusable
