Technical specifications and certifications

• Pipe Size A: 80 mm (3 in)
• Thread B: 2-1/2 (F) NPT
• Maximum Working Pressure: 232 PSI (16 BAR)
• Vacuum Level: 28.94 in Hg / -0.98 BAR
• Working Temperature: -20 to 80 °C

Material(s):
• 100 % Aluminum, EN AB 46100
• Gripping Teeth: Stainless steel
• Seal: NBR with teflon coated treatment

Features and benefits

• Using the innovative one assembly connection technology, the TOPRING PPS fittings are entirely made of Aluminum

2-piece FITTING
• Aluminum body and nut

LEAKPROOF CONNECTION:
• Lubricated teflon coated blue seal
• Perfectly leaktight even under the hardest conditions

HIGH-PERFORMANCE INTERNAL GRIP DESIGN
• Stainless steel ring with gripping teeth for increased grip, strength and safety
• Internal components are securely maintained inside the fitting
• It is a great advantage, especially during installation, because it prevents the components to fall in pieces and it eliminates reassembly errors

Caution

• Installation of TOPRING PPS compressed air piping system must be made according to the assembly instructions as indicated in the installation guide
• Carefully read the technical manual and the installation guide prior to proceeding

Applications

• Compressed air
• Vacuum
• Inert gases
