• Thread: 1 (F) NPT
• Working Temperature: -20 to 200 °C
• Maximum Working Pressure: 2025 PSI
• GPM Maximum Flow: 39.6
Material(s):
• Body: Brass
• Locking mechanism: Stainless steel 304
• Seals: FKM (Viton) fluoroelastomer
• Accept all "ISO-B" interchange type plugs (7241)
• High flow-rate with low pressure drop
• Long, service-free performance
• Hardened at all points of extra stress and wear
• All interior components are corrosion-resistant
• Ball-locking mechanism is engineered for even load distribution assuring positive alignment and allowing hose-protecting swivel action
• These couplers and plugs should never be connected or disconnected under pressure
• Hydraulic fluids, compressed air and water
• All installations where fluid loss during connection or disconnection is unwanted
